Description
It’s what’s INSIDE that counts.
HIGHLIGHTS:
- Capacity with Machine screws : M4 – M8 (5/32″ – 5/16″)
- Capacity with Standard bolt : M5 – M14 (3/16″ – 9/16″)
- Capacity with High tensile bolt : M5 – M12 (3/16″ – 1/2″)
- Length capacity with Coarse thread : 22 – 125 mm (7/8″ – 4-7/8″)
- Impacts per minute : 0 – 3,200 ipm
- No load speed : 0 – 2,300 rpm
- Maximum fastening torque : 160 N.m (1,420 in.lbs)
DESCRIPTION:
- The Makita DTD146 Cordless Impact Driver features ergonomically designed handle and 4-pole motor, plus compact design, enhanced dust and drip-proof performance and battery fuel gauge.
FEATURES
- Very compact with overall length of only 138mm
- Weighs only 1.5kg
- One touch bit installation
- Phosphorescent bumper
- Enhanced dust and drip-proof performance
- Battery level indicator
- Compact and lightweight, 4-pole motor
- LED Job light with afterglow
- Forward/reverse rotation
- Variable speed trigger
- Electronic brake
SPECIFICATION
- Voltage: 18v
- Max Torque (Nm): 160
- Brake Type: Electric
- LED Job Light: Yes / Pre-glow & After-glow
- Battery Capacity Indicator: Yes
- Battery Compatibility: 18v Lithium-Ion (LXT)
- Rotation: Forward & Reverse
- Variable Speed Control Trigger: Yes
- No Load Speed (RPM): 0-2300
- Machine Screw Capacity: M4-M8
- Standard Bolt Capacity: M5-M14
- High Tensile Bolt Capacity: M5-M12
- Coarse Thread Length Capacity (mm): 22-125
- Max. Impacts Per Minute (ipm): 0-3200
- Driving Shank: 1/4″ Hex
- Overall Length (mm): 138
- Net Weight (Kg with 1.5/2Ah Battery): 1.3
- Net Weight (Kg with 3/4/5Ah Battery): 1.5
NOISE & VIBRATION
- Sound Pressure Level (LpA): 93 dB (A)
- Sound Power Level (LWA): 104 dB (A)
- Sound Uncertainty (K): 3 dB (A)
- Vibration Emission (ah) (Using Max Capacity of Tool): 15.5 m/s²
- Vibration Uncertainty (K): 2.0 m/s²
